Cardboard Slitting Machine
Pioneers in the industry, we offer thin blade slitter scorer and cardboard slitting machines from India.High-Lights Of This Model
BEST
QUALITY
HIGH
SPEED
100%
ACCURACY
100%
CAPACITY
![download (10)](https://monugraphics.in/wp-content/uploads/2023/12/download-10.png)
Specification Details
![](https://monugraphics.in/wp-content/uploads/2024/01/expand.png)
Size
2200, 2400, 2600, 2800, 3000
![](https://monugraphics.in/wp-content/uploads/2024/01/weight.png)
Voltage
440V
![](https://monugraphics.in/wp-content/uploads/2024/01/settings.png)
Material
Mild Steel
![](https://monugraphics.in/wp-content/uploads/2024/01/guarantee.png)
Warranty
1 Year
![](https://monugraphics.in/wp-content/uploads/2024/01/best-price.png)
Price
Rs 4.15 Lakh / Unit
Thin Blade Slitter Scorer
Available sizes-2200, 2400, 2600, 2800, 3000mm
Approx. Price: Rs 4.15 Lakh / Unit![](https://monugraphics.in/wp-content/uploads/2023/08/PDF_file_icon.svg_.png)
Product Brochure
Brand | Classic |
Minimum Order Quantity | 1 Piece |
Body Material | Mild Steel |
Usage/Application | Box Making Machine |
Colour | Orange and White |
Country | Made In India |
Automatic Grade | Semi-Automatic |
Size | 1320 mm |
Model Name/Number | MIMT-2500 |
Phase | 3 Phase |
Width of Paper Board | 2500mm |
Max. Speed | 141m/min |
Min. Creasing Width | 200mm |
Min. Slitting Width | 160mm |
Outer Diameter of Thin Round Edge Knife | 260mm |
Thickness of Thin Round Edge knife | 1mm |
Motor Power | 4 kW |
Over View Dimension | 3310x1460x1530 mm |
Machine Weight | 3800 Kg |
Voltage | 440V |
Frequency | 50 Hz |
To fulfill the varying needs of the clients, we are offering Thin Blade Slitter Scorer which is exclusively designed as per their specific requirements. It is highly suitable for the industrial applications owing to its quality as per the international standards, robustness and optimum performance for longer time.
- Assembled with the electric counter to precisely control the quantity of paperboard lines without cracking.
- The electromagnetic speed regulation motor adopted on the main motor, step-less speed changing is available at the range of 0-70 pages/min. Easy for the users.
- Thin edge slitter (1mm thickness) is adopted with an automatic and manual grindstone to keep the knife edge sharp and make slit paper smooth and tidy.
- Pre-pressed paper feeding with the lower pre-pressed solid bearing covered by rubber ensures stable paper transmission and good pre-press results.
- Creasing on slit pre-pressed paperboard with lower creasing solid roller covered by rubber ensures the original.
- Step less speed variation is available at 0-70 pages/min.
- Thin edge slitter with 1mm thickness is installed with automatic and manual grindstone in order to keep the knife edge very sharp as well as make slit paper tidy and smooth.
- Manufactured with an electric counter in order to precisely control the entire quantity of paperboard lines leaving no cracks.
- Main motor is equipped with an electromagnetic speed regulation motor.
Technical Parameter | Corrugation Thin Edge Slitter |
Width of Paper Board | 2000 mm |
Max. Speed | 141m/min |
Min. Creasing width | 200mm |
Min. Slitting Width | 160mm |
Outer Diameter of Thin Round Edge Knife | 260mm |
Thickness of Thin Round Edge knife | 1mm |
Motor Power | 4KW |
Over View Dimension | 2890×1460×1500 MM |
Machine Weight | 3000 kg |
Power | 440 volts for 3 phase &220 volts for Single Phase 50HZ |
Specification Details
![](https://monugraphics.in/wp-content/uploads/2024/01/expand.png)
Size
75″, 85″, 95″, 105″, 110
![](https://monugraphics.in/wp-content/uploads/2024/01/weight.png)
Weight
1250 Kg
![](https://monugraphics.in/wp-content/uploads/2024/01/settings.png)
Material
Mild Steel
![](https://monugraphics.in/wp-content/uploads/2024/01/guarantee.png)
Warranty
1 Year
![](https://monugraphics.in/wp-content/uploads/2024/01/best-price.png)
Price
Rs 3.50 Lakh / Unit
Four Bar Rotary cutting & Creasing Machine
Available sizes-75″, 85″, 95″, 105″, 110″
Approx. Price: Rs 3.50 Lakh / Unit![](https://monugraphics.in/wp-content/uploads/2023/08/PDF_file_icon.svg_.png)
Product Brochure
Brand | Classic |
Minimum Order Quantity | 1 Piece |
Body Material | Mild Steel |
Usage/Application | Box Making Machine |
Colour | Grey and Blue |
Country | Made In India |
Automatic Grade | Automatic |
Size | 75, 85, 95, 105, 110, 120, 130 inch |
Weight | 1250 Kg |
Voltage | 380V |
MDF Thickness | 1~3 mm |
Cardboard Thickness | 1-4 mm |
Power Consumption | 1.5kW |
Dimension (L x W x H) | 2050 x 1320 x 1350mm |
Minimum Cardboard Size | 140*120mm |
Thin Paper Thickness | 0.8-4 mm |
