Flute Laminator Machine
Our range of products include automatic flute laminating machine, roll to roll lamination machine, cold lamination machine, thermal lamination machine and window lamination machine
High-Lights Of This Model
BEST
QUALITY
HIGH
SPEED
100%
ACCURACY
100%
CAPACITY
Specification Details
Size
1100×1100, 1100×1300, 1100×1400 1200x1600mm
Weight
5500 Kg
Material
Mild Steel
Warranty
1 Year
Price
Rs 29.75 Lakh / Piece
3-Ply Automatic Flute Laminator Machine
Available sizes-1100×1100, 1100×1300, 1100×1400 1200x1600mm
Approx. Price: Rs 29.75 Lakh / Piece
Product Brochure
| Brand | Classic |
| Minimum Order Quantity | 1 Piece |
| Body Material | Mild Steel |
| Usage/Application | Box Making Machine |
| Colour | white and Grey |
| Country | Made In India |
| Automatic Grade | Semi-Automatic |
| Phase | 3 Phase |
| Power Source | 7 kW |
| Rated Voltage | 380V |
| Weight | 5500 Kg |
The machine adopts unique pressing spring front lay registration design with plc control system which make run at high lamilation process and low rate of breaking down.The machine users frequency inverter for speed regulation, plc central simulation to digit program system, double servo motors are used to control bottom sheet to get the front lay timely and accurately.Thus the machine accuracy is ensures even in operation adjusting condition.
Specification Details
Size
20″, 25″, 30″
Weight
65 Kg
Material
Mild Steel
Warranty
1 Year
Price
Rs 3.50 Lakh / Piece
Thermal Lamination Machine
Available sizes-20″, 25″, 30″
Approx. Price: Rs 3.50 Lakh / PieceProduct Brochure
| Brand | Classic |
| Minimum Order Quantity | 1 Piece |
| Body Material | Mild Steel |
| Usage/Application | Lamination |
| Colour | white and red |
| Country | Made In India |
| Automatic Grade | Semi-Automatic |
| Rated Voltage | AC 220 V |
| Power Consumption | 2 kW |
| Phase | Single Phase |
| Weight | 65 Kg |
| Dimension | 940 mm x 470 mm x 325 mm |
| Frequency | 50 Hz |
| Maximum Laminating Width | 685 mm |
- Ideal for Laminating Blue prints, Maps, Charts, Technical Data, etc.
- Item Code: 06
- Delivery Time: 30 days
- Packaging Details: this machine is useable to laminate printed paper
Specification Details
Size
24″, 30″, 32″, 36″, 42″
Weight
400 Kg
Material
Mild Steel
Warranty
1 Year
Price
Rs 2.65 Lakh / Piece
Cold Lamination Machine
Available sizes-24″, 30″, 32″, 36″, 42″
Approx. Price: Rs 2.65 Lakh / PieceProduct Brochure
| Brand | Classic |
| Minimum Order Quantity | 1 Piece |
| Body Material | Mild Steel |
| Usage/Application | Lamination on Printing Sheet |
| Colour | Grey |
| Country | Made In India |
| Automatic Grade | Semi-Automatic |
| Model Name/Number | 720 MGCL |
| Weight | 400 Kg |
| Laminating Speed | 40 m/min |
| Phase | 3 Phase |
| Laminating Width | 620 mm |
| Laminating Temperature | 130 Degree C |
| Paper Thickness | Greater Than 80 GSM |
| Electrical Load | 4 kW |
| Line Voltage | 380 V |
| Overall Dimensions | 1900 x 1300 x 1600 mm |
| Model | 720 | 920 | 1200 |
| Laminating Width | 620 mm | 820 mm | 1100 mm |
| Laminating Speed | 0-40 m/min | 0-40 m/min | 0-40 m/min |
| Laminating Temperature | 60-130oC | 60-130oC | 60-130oC |
| Paper Thickness | > 80 gsm | > 80 gsm | > 80 gsm |
| Electrical Load | 4 KW | 6 KW | 6.5 KW |
| Line Voltage | 380V/3Phase | 380V/3Phase | 380V/3Phase |
| Weight | 400 Kg | 500 Kg | 600 Kg |
| Overall Dimensions | 1900x1300x 1600+ mm | 1900x 1500x 1600 mm | 1900x 1700x 1600 mm |
- Production Capacity: 10 Machine Per Month
- Delivery Time: 30 Days
- Packaging Details: This Cold Lamination in Printing Press & Corrugated Box Making Plant to Laminate Printed Paper Sheet.
